Checkering tool C-1 has 1 pyramidal tooth. Angle top 90 degrees. All the cutters are made of steel, undergone the process of hardening and processing, for long and reliable work.
It is V-shaped with teeth on both sides. Checkering tool C-1 is designed for applying the original layout of the picture, as well as for deepening the grooves after their application, with other cutters.
The wooden handle is made of beech, well balanced and lies comfortably in your hand.
Pay attention to the high relief, providing fast and smooth cutting. The tines provide good removal of all hardwoods.
The cutter doesnt look like cutting - deep or shallow grooves, right or rounded corners, parallel lines or cross-hatching, in the direction of the fiber or across. No need to re-do the pass to treat uneven areas. Equal each element is obtained.

The width of the working part is 5 mm, the length of the working part is 11 mm, the apex angle 90 degrees.

Totally hand made at PETROGRAD factory of joinery and carpentry tools. Made in Russia.

Checkering tool No2. Both sides with teeth. Used for the application of grooves and their deepening after application. One blade runs along the guideline, while the other marks the next groove. When moving to the next groove, the tool deepens it and again applies the next groove. Cutter 2 It is a combination of tools for expanding and deepening grooves. Beech handle. All the cutters are made of steel, underwent a process of hardening and processing, for long and reliable work.

Totally hand made at PETROGRAD factory of joinery and carpentry tools. Made in Russia.



Straight and flat leather Knife type 1 with a single bevel (up or right). This model has one flat side and one bevel side. It's simple knife for paring and skiving.

• for straight cuts
• for skiving
• for paring

Flat Leather knife type 1 by Petrograd toolworks comes with a leather sheath. Edge is perfectly sharpened and ready to work out of the box.
This type of knives is used in handicraft, leather work, and shoemaking.

• blade made of tool alloy steel 9ХФ
• blade thickness - 1.7 mm
• edge lenght - 40 mm
• blade lenght - 70mm
• handle made of wood *
• oil covered **

Straight Gouge Rubankov, N3, 6mm

Straight Gouge Rubankov, N3, 6mm (0.43 inches)
Carving chisel "Rubankov" Straight Gouge N3, 6mm (0.43 inches). This is universal chisel that perfectly suits for carving hard and soft wood. The width of the cutting edge is 6mm ( 0.43 inches ). The total lenght of the gouge is 280mm (11.02inches ), blade lenght is 145mm ( 5.71inches ), the lenght of the handle is 135mm (5.31inches ). Made of alloy steel, hand forged and hardened to 59-61HRc. The comfortable and ergonomic oval handle is made of cherrywood ( may change) and coated with oil.

Gouge is sharpened, honed and fully ready to work out of the box.
Produced by PETROGRAD toolworks. ( Saint-Petersburg Russia )

A professional level cutting tool designed for processing hardwoods and hardwoods. The basis of any set of carving tools is straight chisels. Straight chisels "fish tail" (FT) are suitable for solving problems from creating curly shapes to the selection of lamps, allow you to work in hard-to-reach places where a regular straight chisel cannot handle. They can be used beveled up or down to create concave or convex surfaces.
RUBANKOV chisels are forged from low-alloy high-carbon steel. Hardened to a hardness of 59-61 HRc.
The faceted handle is made of precious wood and covered with oil. The impact side is rounded so as not to crush calluses on the palms. The brass ring has an exquisite look and the effect of the handle from cracking when working with a mallet. The internal profile of the chisel is polished, the detected edge is sharpened and ready for work.
These models are percussion, they can be paired with a mallet.
The declared geometric dimensions vary in handling, as the tool is made and hoarded by hand.
The length of the metal sheet is 145 mm. Overall length with handle 280mm.
Web width - 14mm.

Made at the PETROGRAD joinery and carpentry tools factory.
Production Russia.

Straight carving gouge N1 has 10mm wide blade(0.39 inches) and slight profile for better carving abilities. It is universal wood carving chisel that perfectly suits for carving hard or soft wood. Best choice for relief wood carving.

• cutting edge width - 10mm (0.39 inches)
• blade lenght is 145mm (5.71inches)
• Made of alloy steel
• hand forged
• hardened to 59-61HRc

Gouge is sharpened, honed and fully ready to work out of the box.

Produced by PETROGRAD toolworks. ( Saint-Petersburg Russia )
